Sealing Machine User Manual EF101-CR

Technical Specifications:

• 7-inch capacitive color touch screen

• Built-in printer for printing information such as sterilization date, expiration date, operator name, etc.

• Adjustable parameters with automatic data storage

• Temperature control accuracy: ≤ ±1%

• Working temperature: 60–220°C

• Heating rate: 20 → 180°C in 40 seconds

• Heating rate: 120 → 180°C in 10 seconds

• Rapid cooling: 180 → 120°C in 40 seconds

• Sealing speed: 10 ± 0.5 m/min

• Seal width: 12 mm

• Seal margin: 0–35 mm

• Power supply: AC 220V, 50Hz
